3417 Series 5mm HTD Pitch Set Screw Pinion Timing Belt Pulley (8mm REX Bore, 16 Tooth)

SKU:
$8.99

Engineered specifically for 5mm HTD belts with widths of 9mm or less, this 24 tooth, 8mm REX bore pinion pulley features a profile-matched bore to create a positive drive, while a pair of set-screws prevent the pulley from moving axially on a shaft. Built-in shims on each side allow the pulley to rest against a bearing while providing clearance between the pulley and the bearing’s outer race.

Specs

Weight 28g
Material Aluminum
Finish Clear Anodized
Tooth Count 16
Pitch 5mm (HTD)
